Delta-Core Phase-Shifting Rectifier Transformer
The Delta-Core Phase-Shifting Rectifier transformer for Applications is designed for rectification systems that require compact size, efficient material utilization, and balanced electrical performance. It is particularly suitable for small- and medium-capacity applications where voltage transformation, electrical isolation, and phase-shift angle generation must be achieved within limited installation space.
Through optimized winding arrangement, insulation design, and structural layout, the transformer integrates voltage conversion, isolation, and phase-shifting functions into one compact unit, making it an ideal solution for modern rectifier systems.
Delta-Core Phase-Shifting Rectifier Transformer
The Delta-Core Phase-Shifting Rectifier transformer for Applications is designed for rectification systems that require compact size, efficient material utilization, and balanced electrical performance. It is particularly suitable for small- and medium-capacity applications where voltage transformation, electrical isolation, and phase-shift angle generation must be achieved within limited installation space.
Through optimized winding arrangement, insulation design, and structural layout, the transformer integrates voltage conversion, isolation, and phase-shifting functions into one compact unit, making it an ideal solution for modern rectifier systems.
Delta-Core Phase-Shifting Rectifier Transformer
The Delta-Core Phase-Shifting Rectifier transformer for Applications is designed for rectification systems that require compact size, efficient material utilization, and balanced electrical performance. It is particularly suitable for small- and medium-capacity applications where voltage transformation, electrical isolation, and phase-shift angle generation must be achieved within limited installation space.
Through optimized winding arrangement, insulation design, and structural layout, the transformer integrates voltage conversion, isolation, and phase-shifting functions into one compact unit, making it an ideal solution for modern rectifier systems.
Application Areas
Product Features
The transformer adopts an open delta-core structure, providing optimal balance of three-phase magnetic flux and magnetizing current, resulting in lower no-load loss and relatively lower noise.
Compact dimensions:
For 1700 kVA capacity, overall width ≤ 1260 mm;
For 4000 kVA capacity, overall width ≤ 1360 mm.
Small footprint with a compact structural design.
The windings adopt an air-duct cooling structure, providing excellent heat dissipation performance.
Core laminations and copper conductor usage are optimized, resulting in relatively lower manufacturing costs.
Product Features
The transformer adopts an open delta-core structure, providing optimal balance of three-phase magnetic flux and magnetizing current, resulting in lower no-load loss and relatively lower noise.
Compact dimensions:
For 1700 kVA capacity, overall width ≤ 1260 mm;
For 4000 kVA capacity, overall width ≤ 1360 mm.
Small footprint with a compact structural design.
The windings adopt an air-duct cooling structure, providing excellent heat dissipation performance.
Core laminations and copper conductor usage are optimized, resulting in relatively lower manufacturing costs.
Specification
Specification
| Installation | Indoor/Outdoor(with enclosure) |
| Rated Capacity | As required |
| Primary Voltage | Up to 36kV |
| Secondary Voltage | As required |
| Frequency | 50 / 60 Hz |
| Tap Range | As required |
| Impedance Voltage | As required |
| Insulation Class | F (155°C) / H (180°C) |
| Cooling Method | AN / AF |
| Vector Group | As required |
| Winding Material | Copper / Aluminium |
| Degree of Protection | IP00–IP56 |
| Standards | IEC / IEEE |
